MESA CortexLink-A16 ESP32 Board – Product Specifications

Overview

The MESA CortexLink-A16 ESP32 Board is a highly versatile and powerful solution for smart home automation, industrial control, and IoT projects. It features a robust ESP32 dual-core microcontroller that integrates Wi-Fi and Bluetooth connectivity. With 16 MOSFET outputs and 8 digital inputs, this board allows users to build applications for remote control of multiple devices and systems, with support for Modbus RTU, MQTT, HTTP, TCP/IP Ethernet, and other communication protocols.

Product Customization:

This product can be fully customized to meet specific customer requirements. Whether it's adjusting the I/O configurations, modifying connectivity options, or enhancing compatibility with additional modules, the Cortex Link A16 can be tailored to suit your unique project needs. Contact MESA for customization options and pricing.

Availability:

Please note that this product is currently out of stock, but can be manufactured in any quantity upon request. For inquiries, bulk orders, or customization requests, contact MESA directly via email or through our website.

Key Features:

• Microcontroller: ESP32 dual-core processor (240MHz, Tensilica LX6) with built-in Wi-Fi and Bluetooth (BLE & classic)

• 16-Channel MOSFET Outputs: Control relays and other equipment up to 16 independent devices with a load capacity of 12/24VDC 500mA per channel

• 8 Digital Inputs: Monitor external switches, sensors, or other digital devices for system status and automation logic

• Analog Input Capability: Supports 4 Channel 12bit resolution analog inputs (2 x 4 - 20mA Inputs and 2 x DC 0 - 5V) for sensor data collection

• 2 analog outputs (DAC) 0-10V

• 2 x 1-Wire GPIOs for connecting temperature and other sensors

• Multiple Communication Protocols: RS485/Modbus RTU, HTTP, MQTT, TCP/IP, and WebSocket for cloud integration and industrial

• RF 433MHz/315MHz Transmitter and Receiver Interface:

• Wide Software Compatibility: Works with Arduino IDE, PlatformIO, ESPHome, and other development environments

• Over-The-Air (OTA) Updates: Wireless firmware updates and configuration changes

Technical Specifications:

• Microcontroller:

  • Processor: ESP32, dual-core, 32-bit

  • Clock Speed: 240 MHz

  • Memory: 520KB SRAM, 8MB Flash

  • Wireless: 802.11 b/g/n Wi-Fi and Bluetooth 4.2 (BLE and classic)

• Digital Outputs:

  • 16 MOSFET Outputs

  • Voltage Rating: 12/24V DC

  • Current Rating: 500mA per channel

• Digital Inputs:

  • 8 optically isolated digital inputs

  • Input Type: Dry N/O contacts

• Analog Inputs:

  • 4 analog input channels (Input Port 1&2: 4-20mA and input port 3&4: 0-5VDC)

  • 12-bit ADC for sensor input

• Power Supply:

  • Logic Voltage: 5V DC

  • MOSFET Power: 12V/24V DC input

• Dimensions:

  • Size: 200mm x 110mm x 45mm

  • Weight: 320g

• Operating Temperature:

  • Range: -40°C to 85°C

• Software and Programming:

  • Compatible with Arduino IDE, ESPHome, ESP-IDF, and PlatformIO

  • Supports MQTT, Modbus RTU, HTTP, and other communication protocols

  • Over-the-air (OTA) firmware update support

• Connectivity:

  • USB, I2C (SCL/SDA), SPI, and PWM

  • Ethernet

Applications:

• Smart Home Automation: Control lighting, HVAC systems, door locks, and appliances with remote access via Wi-Fi or Bluetooth.

• Industrial Automation: Use in factory automation systems to control machinery, conveyors, and other equipment with real-time monitoring.

• IoT and Cloud Projects: Build connected applications using MQTT or HTTP for cloud-based monitoring and control, integrating seamlessly with platforms like AWS IoT, Google Cloud, and others.

• Remote Monitoring and Control: This is ideal for agricultural automation (e.g., irrigation systems), energy monitoring, or smart grid solutions.

Package Includes:

• 1 x CortexLink-A16 ESP32 Board

• 1 x USB Cable

• User Manual (digital download)

Why Choose CortexLink-A16?
The CortexLink-A16 ESP32 board stands out for its combination of reliable hardware, ease of use, and extensive software support. Whether building a DIY home automation system or deploying an industrial automation project, the CortexLink-A16 offers the flexibility and connectivity needed for any modern IoT or control system application.

Certifications and Compliance:

• CE and RoHS-certified

• Fully compliant with international safety and environmental standards

Warranty:

• 6-month limited warranty from the manufacturer.

• Lifetime technical support is available via the MESA official website and community forums.

Buy Now
Make your automation projects easier and more efficient with the CortexLink-A16 ESP32 board. Add to the cart and get started today!

The Cortex Link A16 ESP32 Board is the perfect solution for developers and enthusiasts seeking to create robust automation systems for residential, industrial, or IoT projects. This product is tailored to meet your needs with customizable features and flexible configurations. Contact MESA via email or our website for customization inquiries and bulk orders.
